Product name: WiFi Battery Camera

Product model: K09

Sensor: SC5336 1/2.7" Progressive Scan CMOS

Display resolution: 5.0MegaPixels(2880H x 1620V)

Minimum illumination: 0.02Lux@(2.0,AGC ON),0Lux with IR

Lens: F/L:3.35MM F/NO:2.0

Viewing angle: Diagonal:140.8° Horizontal: 112° Vertical:57.2°

Day and night conversion mode: ICR infrared filter type

WIFI: USB low-power WIFI module XR8710

Memory: DDR:64MB Flash:16MB

PIR: 3-7 meters, digital PIR sensor sensitivity adjustable

Radar: 5.4G digital radar

Light detection: soft photosensitive

Indicator lights: one red, one blue

Audio input: supports single channel (MIC)

Audio output: single Speaker (4Ω/1W)

Power interface: TYPE-C

Storage interface: 32G built-in EMMC

Power button: support

Network distribution/REST button: supported

Light panel: infrared + white light

Image compression: Main stream H.265 Sub-rate: H.264

Image frame rate: 15fps (3K)

Video bit rate: Main stream (HD) 3.2~4.5Mbps Sub-stream (SD): 512Kbps

Resolution: Main stream: 3K (2880H x 1620V), sub-stream: 720P

Number of simultaneous users: 4

Image flip: support

Infrared mode: automatic

App preview time: 3~4 seconds (cold start)

First frame rendering time: 300ms

Night vision distance: 10M distance 3M details

Input/Output: Full-duplex two-way audio

Audio compression: PCM

Local storage: built-in EMMC

Cloud storage: event recording

Wireless standard: IEEE802.11b/g/n

Data rate: IEEE802.11b: 11Mbps(Max.); IEEE802.11g: 54Mbps(Max.); IEEE802.11n: 150Mbps(Max.).

Wireless security: WEP/WPA/WPA2

Remote access: P2P

Network protocol: HTTP, HTTPS, TCP, IPV4, IPV6, UDP, RTSP, ICMP, RTP, DHCP, ARP, DNS

Platform: Tuya Smart Cloud Platform

APP: Android IOS

OTA: Support

Cloud storage: independent activation

Network distribution method: Bluetooth/QR code

Power supply specification: 5V

Power consumption: 2W Watts (Max.)

Standby sleep current: less than 500uA (power consumption may vary depending on router brand)

Battery: 10000 mAh

Working temperature: -20°C ~ 55°

Working humidity: 10% ~ 95% non-condensing

Storage temperature: -20°C ~ 60°

Storage humidity: 0% ~ 90% non-condensing
